MTS Systems Temposonics R Series User Manual

10
Temposonics
®
R-Series SSI
Operation Manual
Temposonics
®
R-Series SSI
Operation Manual
f Output
S (17) (18) (19) (20) (21) (22) (23) (24) (25)
= Synchronous Serial Interface
Data length (box no. 17)
1
25 bit
2
24 bit
3
26 bit
Output format (box no. 18)
B
Binary
G
Gray
Resolution (box no. 19)
1
0.005 mm
2
0.01 mm
3
0.05 mm
4
0.1 mm
5
0.02 mm
6
0.002 mm
8
0.001 mm
Filtering performance (box no. 20)
A
No filter + error delay (4 cycles)
C
No filter + error delay (8 cycles)
1
Standard (no filters)
8
Noise reduction filter (8 measurements)
D
No filter + error delay (10 cycles)
G
Noise reduction filter (8 measurements) + error delay (10 cycles)
K
Peak reduction filter (8 measurements)
N
Peak reduction filter (8 measurements) + error delay (10 cycles)
Signal options (box no. 21, 22)
0 0
Measuring direction forward, asynchronous mode
0 1
Measuring direction reverse, asynchronous mode
0 2
Measuring direction forward, synchronous mode 1
0
5
Measuring direction forward, asynchronous mode,
bit 25 = alarm, bit 26 = parity even
9 9
Write “9” in box no. 21 and 22 for using further
combinations in boxes 23, 24, 25.
f Output (continued)
Measurement contents (optional: box no. 23)
Note: Choose “9” in box no. 21 and 22.
1
Position measurement
2
Differentiation measurement
8
3
Velocity measurement
4
Position measurement + temperature measurement
(only with data length = 24 bit)
5
Differentiation measurement
8
+ temperature measurement
(only with data length = 24 bit)
6
Velocity measurement + temperature measurement
(only with data length = 24 bit)
Direction and sync. mode (optional: box no. 24)
Note: Choose “9” in box no. 21 and 22.
1
Measuring direction forward, asynchronous mode
2
Measuring direction forward, synchronous mode 1
3
Measuring direction forward, synchronous mode 2
4
Measuring direction forward, synchronous mode 3
5
Measuring direction reverse, asynchronous mode
6
Measuring direction reverse, synchronous mode 1
7
Measuring direction reverse, synchronous mode 2
8
Measuring direction reverse, synchronous mode 3
Only available for flanges »C« / »D«, »G« & »M« / »T«
Internal linearization & diagnostics (optional: box no. 25)
Note: Choose “9” in box no. 21 and 22.
0
No further options
1
Internal linearization
2
Additional alarm bit + parity even bit
(not available for temperature output, only with data length
= 24 bit)
4
Additional alarm bit + parity even bit and internal linearization
(not available for temperature output, only with data length
= 24 bit)
8/ You need a second magnet for differentiation measurement
