Temposonics
®
R-Series SSI
Operation Manual
Temposonics
®
R-Series SSI
Operation Manual
Output
Interface SSI (Synchronous Serial Interface) – differential signal in SSI standard (RS 422)
Data format Binary or gray, optional parity and error bit or temperature of sensor electronics
Data length 8…32 bit
Data transmission rate 70 kBaud*…1 MBaud, depending on cable length:
Cable length < 3 m < 50 m < 100 m < 200 m < 400 m
Baud rate 1 MBd < 400 kBd < 300 kBd < 200 kBd < 100 kBd
Measured value Position, differentiation measurement, velocity, temperature of sensor electronics
Measurement parameters
Resolution Position: 0.5 μm, 1 μm, 2 μm, 5 μm, 10 μm, 20 μm, 50 μm, 100 μm /
Velocity over 10 measured values: 0.1 mm/s (at 1 ms cycle time)
Cycle time Stroke length 300 mm 750 mm 1000 mm 2000 mm 5000 mm
Measurement rate 3.7 kHz 3.0 kHz 2.3 kHz 1.2 kHz 0.5 kHz
Linearity
14
< ±0.01 % F.S. (minimum ±40 μm)
Option internal linearization
Linearity tolerance:
< 300 mm: typ. ±15 μm, max. ±25 μm
300 … 600 mm: typ. ±20 μm, max. ±30 μm
600…1200 mm: typ. ±30 μm, max. ±50 μm
1200…3000 mm: typ. ±45 μm, max. ±90 μm
3000…5000 mm: typ. ±85 μm, max. ±150 μm
Repeatability < ±0.001 % F.S. (minimum ±2.5 μm) typical
Hysteresis < 4 μm typical
Temperature coefficient < 15 ppm / K typical
Operating conditions
Operating temperature −40…+75 °C (−40…+167 °F)
Humidity 90 % rel. humidity, no condensation
Ingress protection
15
IP65
Shock test 100 g (single shock), IEC standard 60068-2-27
Vibration test 15 g / 10…2000 Hz, IEC standard 60068-2-6 (resonance frequencies excluded)
option: Vibration resistant 30 g (av)
EMC test Electromagnetic emission according to EN 61000-6-3
Electromagnetic immunity according to EN 61000-6-2
The sensor meets the requirements of the EC directives and is marked with
Magnet movement velocity Magnet slider: Max. 10 m/s; U-magnet: Any; block magnet: Any
Design / Material
Sensor electronics housing Aluminum
Sensor profile Aluminum
Stroke length 25…5080 mm (1…200 in.)
Mechanical mounting
Mounting position Any orientation
Mounting instruction Please consult the technical drawings on page 17
8. Technical data
8.1 Technical data of Temposonics
®
RP
See next page for section “Electrical connection”
*/ With standard one shot of 16 μs
14/ With position magnet # 252 182
15/ The IP rating is not part of the UL recognition
