48
Temposonics
®
R-Series SSI
Operation Manual
Temposonics
®
R-Series SSI
Operation Manual
Electrical connection
Connection type M16 (7 pin) male connector or cable outlet
Operating voltage +24 VDC (−15 / +20 %);
UL Recognition requires an approved power supply with energy limitation (UL 61010-1),
or Class 2 rating according to the National Electrical Code (USA) / Canadian Electrical Code.
Ripple ≤ 0.28 V
pp
Current consumption 100 mA typical
Dielectric strength 500 VDC (DC ground to machine ground)
Polarity protection Up to −30 VDC
Overvoltage protection Up to 36 VDC
