Output
Interface SSI (Synchronous Serial Interface) – differential signal in SSI standard (RS 422)
Data format Binary or gray, optional parity and error bit or temperature of sensor electronics
Data length 8…32 bit
Data transmission rate 70 kBaud*…1 MBaud, depending on cable length:
Cable length < 3 m < 50 m < 100 m < 200 m < 400 m
Baud rate 1 MBd < 400 kBd < 300 kBd < 200 kBd < 100 kBd
Measured value Position, differentiation measurement, velocity, temperature of sensor electronics
Measurement parameters
Resolution Position: 2 μm, 5 μm, 10 μm, 20 μm, 50 μm, 100 μm /
Velocity over 10 measured values: 0.1 mm/s (at 1 ms cycle time)
Cycle time Stroke length 300 mm 750 mm 1000 mm 2000 mm 5000 mm 10,000 mm 20,000 mm
Measurement rate 3.7 kHz 3.0 kHz 2.3 kHz 1.2 kHz 0.5 kHz 0.25 kHz 0.125 kHz
Linearity
23
< ±0.02 % F.S. (minimum ±100 μm)
Repeatability < ±0.001 % F.S. (minimum ±2.5 μm) typical
Hysteresis < 4 μm typical
Operating conditions
Operating temperature −40…+75 °C (−40…+167 °F)
Humidity 90 % rel. humidity, no condensation
24
Ingress protection IP30 (IP65 rating only for professional mounted guide pipe and if mating connectors are correctly
fitted)
Shock test 100 g (single shock) IEC standard 60068-2-27
Vibration test 5 g / 10…150 Hz IEC standard 60068-2-6 (resonance frequencies excluded)
EMC test
25
Electromagnetic emission according to EN 61000-6-3
Electromagnetic immunity according to EN 61000-6-2
The sensor meets the requirements of the EC directives and is marked with
Magnet movement velocity Any
Design / Material
Sensor electronics housing Aluminum
Sensor rod Stainless steel conduit with PTFE coating
Stroke length 150…20,000 mm (6…787 in.)
Operating pressure 350 bar (5076 psi) for RF with pressure rod HD / HL / HP (see accessories on page 39)
Mechanical mounting
Mounting position Any orientation
Mounting instruction Please consult the technical drawings on page 31
8.5 Technical data of Temposonics
®
RF
See next page for section “Electrical connection”
*/ With standard one shot of 16 μs
23/ With position magnet # 251 416-2
24/ For professional mounted guide pipe and if mating connectors are correctly fitted
25/ The conformity is fulfilled, assumed the wave guide of the sensor is embedded in an
EMC-sealed and grounded housing
