Output
Interface SSI (Synchronous Serial Interface) – differential signal in SSI standard (RS 422)
Data format Binary or gray, optional parity and error bit or temperature of sensor electronics
Data length 8…32 bit
Data transmission rate 70 kBaud*…1 MBaud, depending on cable length:
Cable length < 3 m < 50 m < 100 m < 200 m < 400 m
Baud rate 1 MBd < 400 kBd < 300 kBd < 200 kBd < 100 kBd
Measured value Position, differentiation measurement, velocity, temperature of sensor electronics
Measurement parameters
Resolution Position: 1 μm, 2 μm, 5 μm, 10 μm, 20 μm, 50 μm, 100 μm /
Velocity over 10 measured values: 0.1 mm/s (at 1 ms cycle time)
Cycle time Stroke length 300 mm 750 mm 1000 mm 2000 mm 5000 mm
Measurement rate 3.7 kHz 3.0 kHz 2.3 kHz 1.2 kHz 0.5 kHz
Linearity
18
< ±0.02 % F.S. (minimum ±50 μm)
19
Repeatability < ±0.001 % F.S. (minimum ±2.5 μm) typical
Hysteresis < 4 μm typical
Operating conditions
Operating temperature −40…+75 °C (−40…+167 °F)
Humidity 90 % rel. humidity, no condensation
Ingress protection Sensor electronics: IP67 (with professionally mounted housing and connectors)
Rod with connecting cable for side cable entry: IP65
Rod with single wires and flat connector with bottom cable entry: IP30
Shock test 100 g (single shock) IEC standard 60068-2-27
Vibration test 10 g / 10…2000 Hz IEC standard 60068-2-6 (resonance frequencies excluded)
EMC test
20
Electromagnetic emission according to EN 61000-6-3
Electromagnetic immunity according to EN 61000-6-2
Magnet movement velocity Any
Design / Material
Sensor electronics housing Aluminum
Sensor rod Stainless steel 1.4306 (AISI 304L)
Stroke length 25…5080 mm (1…200 in.)
Operating pressure 350 bar (5076 psi), 700 bar (10153 psi) peak (at 10 × 1 min)
Mechanical mounting
Mounting position Any orientation
Mounting instruction Please consult the technical drawings on page 21 and on page 23
8.3 Technical data of Temposonics
®
RD4
See next page for section “Electrical connection”
*/ With standard one shot of 16 μs
18/ With position magnet # 251 416-2
19/ For pressure fit flange »S« the linearity deviation can be higher in the first 30 mm (1.2 in.) of stroke length
20/ Sensor rod and connecting cable have to be mounted in a metal housing (e.g. in a cylinder)
