9
Temposonics
®
R-Series SSI
Operation Manual
Temposonics
®
R-Series SSI
Operation Manual
b Design
C
Threaded flange M18×1.5-6g, A/F 46
D
Threaded flange ¾"-16 UNF-3A, A/F 46
G
Threaded flange M18×1.5-6g, A/F 24
M
Threaded flange M18×1.5-6g, A/F 23
S
Pressure fit flange Ø 26.9 mm f6
T
Threaded flange ¾"-16 UNF-3A, A/F 23
a Sensor model
R D
4
Detached sensor electronics
c Integral cable of sensor rod
For side cable entry on sensor electronics housing
D 1
S
PUR cable with M16 connector,
length 250 mm (9.8 in.)
D 2
S
PUR cable with M16 connector,
length 400 mm (15.7 in.)
D
3
S
PUR cable with M16 connector,
length 600 mm (23.6 in.)
For bottom cable entry on sensor electronics housing
R
2
B
PUR cable / wires with flat connector,
length 65 mm (2.6 in.)
R 4
B
PUR cable / wires with flat connector,
length 170 mm (6.7 in.)
R
5
B
PUR cable / wires with flat connector,
length 230 mm (9.1 in.)
R
6
B
PUR cable / wires with flat connector,
length 350 mm (13.8 in.)
R
D
4
S
a b c d e f
23, 24, 25: Optional
Operating voltage
+24 VDC (−15 / +20 %); Standard, not indicated in order code
d Stroke length
X
X
X X
M
Flange »C« / »D«, »G«, »M« / »T«:
0025…5080 mm
Flange »S«:
0025…2540 mm
X X X X U
Flange »C« / »D«, »G«, »M« / »T«:
001.0…200.0 in.
Flange »S«:
001.0…100.0 in.
.
Standard stroke length (mm)*
Stroke length Ordering steps
25 … 500 mm 5 mm
500 … 750 mm 10 mm
750…1000 mm 25 mm
1000…2500 mm 50 mm
2500…5080 mm 100 mm
Standard stroke length (in.)*
Stroke length Ordering steps
1 … 20 in. 0.2 in.
20 … 30 in. 0.4 in.
30 … 40 in. 1.0 in.
40…100 in. 2.0 in.
100…200 in. 4.0 in.
*/ Non standard stroke lengths are available; must be encoded in 5 mm / 0.1 in.
increments
7/ Encode in meters if using metric stroke length. Encode in feet if using US customary
stroke length
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
18 19 20 21 22 23
24 25
3.3 Order code of Temposonics
®
RD4
f
Continued on next page
e Connection type
D 7 0
M16 (7 pin) male connector
See “Frequently ordered accessories” for cable
connector specifications
F
X X
XX m PUR cable (part no. 530 045)
F01…F10 (1…10 m / 3…33 ft.)
7
See “Frequently ordered accessories” for cable
specifications
H
X X
XX m PUR cable (part no. 530 052)
H01…H10 (1…10 m / 3…33 ft.)
7
See “Frequently ordered accessories” for cable
specifications
M S 0
MS0 (10 pin) male connector
P
X
X
XX m TMPU cable (part no. 530 029)
P01…P10 (1…10 m / 3…33 ft.)
7
See “Frequently ordered accessories” for cable
specifications
R
X X
XX m PVC cable (part no. 530 032)
R01…R10 (1…10 m / 3…33 ft.)
7
See “Frequently ordered accessories” for cable
specifications
