Temposonics
®
R-Series SSI
Operation Manual
Temposonics
®
R-Series SSI
Operation Manual
4.10 Frequently ordered accessories – Additional options available in our Accessories Guide 551 444
Controlling design dimensions are in millimeters and measurements in ( ) are in inches
Position magnets
M5
20
(0.79)
43
(1.69)
14
(0.55)
40 (1.58)
18°
25.3
(1)
M5
40 (1.58)
18°
57 (2.24)
14
(0.55)
25.3 (1)
49 (1.93)
Ø 32.8
(Ø 1.29)
Ø 23.8
(Ø 0.94)
Ø 13.5
(Ø 0.53)
Ø 4.3
(Ø 0.17)
60°
140°
3
(0.12)
7.9
(0.31)
Ø 32.8
(Ø 1.29)
Ø 23.8
(Ø 0.94)
Ø 13.5
(Ø 0.53)
Ø 4.3
(Ø
0.17)
7.9
(0.31)
Magnet slider S
Part no. 252 182
Magnet slider V
Part no. 252 184
U-magnet OD33
Part no. 251 416-2
Ring magnet OD33
Part no. 201 542-2
For: RP For: RP For: RP, RH, RD4, RT4 For: RH, RD4, RT4
Material: GFK, magnet hard ferrite
Weight: Ca. 35 g
Operating temperature:
−40…+75 °C (−40…+167 °F)
Material: GFK, magnet hard ferrite
Weight: Ca. 35 g
Operating temperature:
−40…+75 °C (−40…+167 °F)
Material: PA ferrite GF20
Weight: Ca. 11 g
Surface pressure: Max. 40 N/mm
2
Fastening torque for M4 screws: 1 Nm
Operating temperature:
−40…+105 °C (−40…+221 °F)
Material: PA ferrite GF20
Weight: Ca. 14 g
Surface pressure: Max. 40 N/mm
2
Fastening torque for M4 screws: 1 Nm
Operating temperature:
−40…+105 °C (−40…+221 °F)
Position magnets
Ø 25.4
( Ø 1)
Ø 13.5
(
Ø 0.53)
7.9
(0.31)
Ø 13.5
(Ø 0.53)
Ø 17.4
(Ø 0.69)
7.9
(0.31)
19.5 (0.77)
1.5
(0.06)
33 (1.3)
14
(0.55)
20.5
(0.81)
14.9 (0.59)
8 ± 2 (0.31 ± 0.08)
Distance to sensor element
Ø 4.3
(Ø 0.17)
Ø 19.8
(Ø 0.78)
Ø 30.5
(Ø 1.2)
7.6
(0.3)
Ring magnet OD25.4
Part no. 400 533
Ring magnet OD17.4
Part no. 401 032
Block magnet
Part no. 403 448
Ring magnet
Part no. 402 316
For: RH, RD4, RT4 For: RH, RD4, RT4 For: RP, RH, RF For: RH, RF, RD4
Material: PA ferrite
Weight: Ca. 10 g
Surface pressure: Max. 40 N/mm
2
Operating temperature:
−40…+105 °C (−40…+221 °F)
Material: PA neobind
Weight: Ca. 5 g
Surface pressure: Max. 20 N/mm
2
Operating temperature:
−40…+105 °C (−40…+221 °F)
Material: Hard ferrite
Weight: Ca. 20 g
Fastening torque for M4 screws: 1 Nm
Operating temperature:
−40…+75 °C (−40…+167 °F)
Material: PA ferrite coated
Weight: Ca. 13 g
Surface pressure: 20 N/mm
2
Operating temperature:
−40…+100 °C (−40…+212 °F)
Position magnets
Ø 60
(Ø 2.36)
Ø 48
(Ø 1.89)
Ø 30
(Ø 1.18)
Ø 4.5
(Ø 0.18)
15
(0.59)
Ø 42
(Ø 1.65)
Ø 16
(Ø 0.63)
Ø 4.5 (Ø 0.18)
97°
30°
9.5
(0.37)
Ø 63.5
(Ø 2.5)
Ø 14.3
(Ø 0.56)
Ø 23.8
(Ø 0.94)
Ø 31.8
(Ø 1.25)
Ø 4.3
(Ø 0.17)
3.2
(0.13)
Ring magnet OD60
Part no.
MT0162
U-magnet OD63.5
Part no.
201 553
Magnet spacer
Part no. 400 633
For: RH, RF, RD4 For: RH, RF, RD4 For: RH, RD4, RT4
Material: Al CuMgPb,
Magnets compound-fi lled
Weight: Ca. 90 g
Surface pressure: 20 N/mm
2
Fastening torque for M4 screws: 1 Nm
Operating temperature:
−40…+75 °C (−40…+167 °F)
Material: PA 66-GF30,
Magnets compound-fi lled
Weight: Ca. 26 g
Surface pressure: 20 N/mm
2
Fastening torque for M4 screws: 1 Nm
Operating temperature:
−40…+75 °C (−40…+167 °F)
Material: Aluminum
Weight: Ca. 5 g
Surface pressure: 20 N/mm
2
Fastening torque for M4 screws: 1 Nm
