MTS Systems Temposonics R Series User Manual

15
Temposonics
®
R-Series SSI
Operation Manual
Temposonics
®
R-Series SSI
Operation Manual
3.6 Nameplate
3.7 Approvals
certified (RP / RH / RF), UL approved (RP / RH),
GOST certified (RP / RH / RD4 / RF)
3.8 Scope of delivery
RP (profile sensor):
• Sensor, position magnet
• 2 mounting clamps up to 1250 mm (50 in.) stroke length +
1 mounting clamp for each 500 mm (20 in.) additional stroke length
RH (rod sensor):
• RH-B: Base unit, 2 socket screws M4
• RH-D / -H / -J / -M / -R / -S / -T / -U / -V: Sensor, O-ring
RD4 (detached sensor electronics):
• RD4-C / -D / -G / -M / -T: Sensor, O-ring
• RD4-S: Sensor, O-ring, back-up ring
RT4 (redundant with detached electronics):
• Sensor, O-ring
RF (flexible sensor rod):
• RF-C: Base unit
• RF-M /-S: Sensor, O-ring
Fig. 1: Example of a nameplate of a RH sensor (production site Germany)
Fig. 2: Example of a nameplate of a RH sensor (production site USA)
Order code
Serial number
Coding
output dependent
RHM0425MD701S1G2100
0.01 mm / 25 Bit gray
Grd.: 2797.14 m/s
FNr.: 1413 3950
1237584838239380239842390759348759872
Order code
Serial number
Coding
output dependent
RHT0060UD701S1B1C02
S/N: 90787117
GRD: 9.1132 uS/In 2787.16 m/s
90787117907871179078711790787117
