3.2 Order code of Temposonics
®
RH
R H
a b c d e
b Design
B
Base unit
D
Threaded flange M18×1.5-6g (bushing on rod end)
H
Threaded flange ¾"-16 UNF-3A
(with fluoroelastomer housing-seal)
J
Threaded flange M22×1.5-6g (rod Ø 12.7 mm, 800 bar)
M
Threaded flange M18×1.5-6g (standard)
R
Threaded flange M18×1.5-6g (thread M4 at rod end)
S
Threaded flange ¾"-16 UNF-3A (standard)
T
Threaded flange ¾"-16 UNF-3A (with raised-face)
U
Threaded flange ¾"-16 UNF-3A
(with raised-face & fluoroelastomer housing-seal)
V
Threaded flange M18×1.5-6g (with fluoroelastomer housing-seal)
S
f
20, 21, 22: Optional
a Sensor model
R H
Rod
Standard stroke length (mm)*
Stroke length Ordering steps
25 … 500 mm 5 mm
500 … 750 mm 10 mm
750…1000 mm 25 mm
1000…2500 mm 50 mm
2500…5000 mm 100 mm
5000…7620 mm 250 mm
Standard stroke length (in.)*
Stroke length Ordering steps
1 … 20 in. 0.2 in.
20 … 30 in. 0.4 in.
30 … 40 in. 1.0 in.
40…100 in. 2.0 in.
100…200 in. 4.0 in.
200…300 in. 10.0 in.
c Stroke length
X X X X M
0025…7620 mm
X X X X
U
001.0…300.0 in.
.
e Operating voltage
1
+24 VDC (−15 / +20 %)
A
+24 VDC (−15 / +20 %), vibration resistant
(stroke length 25…2000 mm / 1…79 in.)
*/ Non standard stroke lengths are available; must be encoded in 5 mm / 0.1 in.
increments
5/ Encode in meters if using metric stroke length. Encode in feet if using US customary
stroke length
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
19 20 21 22
f
See next page
d Connection type
D 7 0
M16 (7 pin) male connector
See “Frequently ordered accessories” for cable
connector specifications
F
X X
XX m PUR cable (part no. 530 045)
F01…F10 (1…10 m / 3…33 ft.)
5
See “Frequently ordered accessories” for cable
specifications
H
X X
XX m PUR cable (part no. 530 052)
H01…H10 (1…10 m / 3…33 ft.)
5
See “Frequently ordered accessories” for cable
specifications
M S 0
MS0 (10 pin) male connector
P
X
X
XX m TMPU cable (part no. 530 029)
P01…P10 (1…10 m / 3…33 ft.)
5
See “Frequently ordered accessories” for cable
specifications
R
X X
XX m PVC cable (part no. 530 032)
R01…R10 (1…10 m / 3…33 ft.)
5
See “Frequently ordered accessories” for cable
specifications
To Next Page
