6
Temposonics
®
R-Series SSI
Operation Manual
Temposonics
®
R-Series SSI
Operation Manual
Measurement contents (optional: box no. 20)
Note: Choose “9” in box no. 18 and 19.
1
Position measurement
2
Differentiation measurement
4
3
Velocity measurement
4
Position measurement + temperature measurement
(only with data length = 24 bit)
5
Differentiation measurement
4
+ temperature measurement
(only with data length = 24 bit)
6
Velocity measurement + temperature measurement
(only with data length = 24 bit)
Direction and sync. mode (optional: box no. 21)
Note: Choose “9” in box no. 18 and 19.
1
Measuring direction forward, asynchronous mode
2
Measuring direction forward, synchronous mode 1
3
Measuring direction forward, synchronous mode 2
4
Measuring direction forward, synchronous mode 3
5
Measuring direction reverse, asynchronous mode
6
Measuring direction reverse, synchronous mode 1
7
Measuring direction reverse, synchronous mode 2
8
Measuring direction reverse, synchronous mode 3
Internal linearization & diagnostics (optional: box no. 22)
Note: Choose “9” in box no. 18 and 19.
0
No further options
1
Internal linearization
2
Additional alarm bit + parity even bit
(not available for temperature output, only with data length =
24 bit)
4
Additional alarm bit + parity even bit and internal linearization
(not available for temperature output, only with data length =
24 bit)
4/ You need a second magnet for differentiation measurement
f Output (continued)
Signal options (box no. 18, 19)
0 0
Measuring direction forward, asynchronous mode
0 1
Measuring direction reverse, asynchronous mode
0 2
Measuring direction forward, synchronous mode 1
0
5
Measuring direction forward, asynchronous mode,
bit 25 = alarm, bit 26 = parity even
1
6
Measuring direction forward, asynchronous mode ,
internal linearization
9 9
Write “9” in box no. 18 and 19 for using further
combinations in boxes 20, 21, 22.
