3.5 Order code of Temposonics
®
RF
R F
1
a b c d e
S
f
21, 22, 23: Optional
b Design
C
Base unit
M
Threaded flange M18×1.5-6g
S
Threaded flange ¾"-16 UNF-3A
a Sensor model
R F
Flexible sensor rod
e Operating voltage
1
+24 VDC (−15 / +20 %)
*/ Non standard stroke lengths are available; must be encoded in 5 mm / 0.1 in.
increments
10/ Encode in meters if using metric stroke length. Encode in feet if using US customary
stroke length
c Stroke length
X X X X X
M
00150…20,000 mm
X X X X X
U
0006.0…0787.0 in.
Standard stroke length (mm)*
Stroke length Ordering steps
150 … 1000 mm 50 mm
1000 … 5000 mm 100 mm
5000 …10,000 mm 250 mm
10,000…15,000 mm 500 mm
> 15,000 mm 1000 mm
Standard stroke length (in.)*
Stroke length Ordering steps
6 … 40 in. 2 in.
40…197 in. 4 in.
197…394 in. 10 in.
394…591 in. 20 in.
> 591 in. 40 in.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
19 20 21 22 23
f
Continued on next page
d Connection type
D 7 0
M16 (7 pin) male connector
See “Frequently ordered accessories” for cable
connector specifications
F
X X
XX m PUR cable (part no. 530 045)
F01…F10 (1…10 m / 3…33 ft.)
10
See “Frequently ordered accessories” for cable
specifications
H
X X
XX m PUR cable (part no. 530 052)
H01…H10 (1…10 m / 3…33 ft.)
10
See “Frequently ordered accessories” for cable
specifications
M S 0
MS0 (10 pin) male connector
P
X
X
XX m TMPU cable (part no. 530 029)
P01…P10 (1…10 m / 3…33 ft.)
10
See “Frequently ordered accessories” for cable
specifications
R
X X
XX m PVC cable (part no. 530 032)
R01…R10 (1…10 m / 3…33 ft.)
10
See “Frequently ordered accessories” for cable
specifications
