Temposonics
®
R-Series SSI
Operation Manual
Temposonics
®
R-Series SSI
Operation Manual
f Output (continued)
Filtering performance (box no. 20)
8
Noise reduction filter (8 measurements)
G
Noise reduction filter (8 measurements) + error delay (10 cycles)
Signal options (box no. 21, 22)
0 0
Measuring direction forward, asynchronous mode
0 1
Measuring direction reverse, asynchronous mode
0 2
Measuring direction forward, synchronous mode 1
0
5
Measuring direction forward, asynchronous mode,
bit 25 = alarm, bit 26 = parity even
9 9
Write “9” in box no. 21 and 22 for using further
combinations in boxes 23, 24, 25.
Measurement contents (optional: box no. 23)
Note: Choose “9” in box no. 21 and 22.
1
Position measurement
Direction and sync. mode (optional: box no. 24)
Note: Choose “9” in box no. 21 and 22.
1
Measuring direction forward, asynchronous mode
2
Measuring direction forward, synchronous mode 1
5
Measuring direction reverse, asynchronous mode
6
Measuring direction reverse, synchronous mode 1
Diagnostics (optional: box no. 25)
Note: Choose “9” in box no. 21 and 22.
0
No further options
2
Additional alarm bit + parity even bit
