Temposonics

R-Series SSI

Operation Manual

Temposonics

R-Series SSI

Operation Manual

Electrical connection

Connection type M16 (7 pin) male connector or integral cable

Operating voltage +24 VDC (−15 / +20 %)

Ripple ≤ 0.28 V

Current consumption 100 mA typical per sensor electronics

Dielectric strength 500 VDC (DC ground to machine ground)

Polarity protection Up to −30 VDC

Overvoltage protection Up to 36 VDC
