Mueller ISOBUS SPRAYER-Controller MIDI 3.0 - Extension: TANK-Control II; Extension: EDS

Mounting and installation
System Overview
4
30303187-02-EN
V1.20170116
19
Extension: TANK-Control II
TANK-Control II
Connection to the main system or to a system
add-on, with the option of connecting further
add-ons.
Cable length - Item number:
1m - 3030308901
Connection to the main system or to a system
add-on
1m - 30303089
TANK-Control II - Operating device and
computer.
30252060
Junction box
30252076
Connection for TANK-Control sensor 1
Connection for TANK-Control sensor 2
Extension: EDS
Electrical connection of the EDC components
4.1.4
4.1.5
