Mueller ISOBUS SPRAYER-Controller MIDI 3.0 - Extension: DISTANCE-Control II

4
Mounting and installation
System Overview
18
V1.20170116
30303187-02-EN
Extension: DISTANCE-Control II
DISTANCE-Control II
Connection to ECU MAXI 3.0 or to the last
ECU MIDI.
Cable length - Item number:
0.3m - 30322355
10m - 30322356
6.5m - 30322357
3.2m - 30322358
1.5m - 30322359
Termination plug.
Otherwise, connection of other extensions.
31300581 - Terminating resistor is supplied with the
master job computer and must not be ordered
separately.
Junction box
Item number:
30303167
Job computer
30303165
4.1.3
