Configuring the job computer
Configuring the nozzles - for field sprayers with pressure sensor regulation
Determination of the fitting nozzles
Here, you can enter:
- The intended application rate This is adopted directly from the "Rate" parameter.
- The optimal pressure for the nozzle
Here, you can see the speed at which this application rate can be reached.
To calculate the application rate that can be reached with a nozzle at a given pressure:
1. Switch to the "NOZZLE ASSISTANT" screen:
>
2. - Press for the speed icon to appear in the "User data" area.
3. Select the box with the nozzle colour to select a nozzle.
⇨ The list contains all standard nozzles and four positions for the configuration of custom
nozzles.
4. Enter the intended working speed in the box.
5. In the area, set the optimal pressure range that enables the
intended drop size with the selected nozzle. This value can be found on the nozzle data sheet.
⇨ Note: The pressure range set here will not be adopted for the application. During operation,
you must ensure for yourself that the sprayer is working in the intended pressure range.
⇨ In the "Results" area, the possible application rates appear.
If the calculated application rate is too high or too low:
▪ Change the working speed.
▪ Install different nozzles. Perform the calculation for the new nozzle colour.
The calculation can be performed based on the intended application rate:
1. - Press for the icon to appear in the "User data" area.
2. Enter the intended application rate in the field.
3. Enter the pressure range for the nozzle colour.
