Configuring the job computer
Vario and Select mode - configuring multiple nozzle holders
6. Only install nozzles that have been successfully tested by the job computer and for which there
have been no error messages during the configuration.
Possible nozzle ranges for nozzles are red and grey, in the pressure range from 2 bar to 6 bar
Here, you can see the nozzle combination for
which the bar applies.
Bar with the desired application rate.
The bar always begins at the lowest pressure
and ends at the highest.
Current status of the function. Here: Vario
mode is activated.
Minimum and maximum target rate for all
nozzle combinations.
If some application rates are not possible for a nozzle combination, the display flashes red/yellow:
Possible nozzle ranges for nozzles are red and green, in the pressure range from 1 bar to 6 bar
The display flashes yellow/red. Application rates in the flashing range cannot be achieved with the
selected nozzles.
In many cases, 3 nozzles are used for plant protection in Vario mode, the fourth nozzle is excluded [
➙ 80] from the Vario mode and is only activated manually for liquid fertiliser application.
Vario with a quadruple nozzle holder. The purple nozzle is excluded.
Application rates are calculated without taking
account of the purple nozzle.
Purple nozzle is excluded from the Vario.
In Select mode, the possible application rates are also displayed, but it is not necessary to use a
combination without overlap.
