Mounting and installation
Connecting the terminal to the basic equipment
14 Copyright © Müller-Elektronik GmbH & Co.KG
This basic equipment is available in two models:
▪ Connection via an adapter cable to the tractor's existing signal socket (DIN 9684.1 / ISO 11786).
(Item no.: 30322560)
▪ Equipping the tractor jobcomputer with sensors (km/h transmission, km/h radar, PTO speed and
work position). This equipment offers the possibility of fitting the tractor with a front and rear
power socket. (Item no.: 30322565)
Connecting the terminal to the basic equipment
1. Insert the 9-pin cable of the basic equipment into the 9-pin socket A on the terminal.
2. Tighten the safety screws on the connector.
4.3.3
Procedure
