Maintenance and servicing
Technical specifications
8
Copyright © Müller-Elektronik GmbH & Co.KG 47
Parameter Value
Storage temperature -30 - +80 °C
Weight 1.3 kg
Dimensions (W x H x D) 220 x 210 x 95 mm
Protection class IP 54 in accordance with DIN 40050/15
EMC In accordance with ISO 14982 / PREN 55025
ESD protection In accordance with ISO 10605
At terminal: 30322511
without external equipment
Typically: 0.4 A at 13.8 V Power input
At terminal: 30322512
without external equipment
Typically: 0.5 A at 13.8 V
Display VGA TFT colour display; display size (diagonal): 14.5 cm ; resolution:
640 x 480 pixels
Processor 32-bit ARM920T up to 400 MHz
RAM 64 MB SDRAM
Boot USB 128 MB
Internal clock Buffered by capacitor, keeps the time for 2 weeks without an external
power supply.
Keyboard 17 keys plus rotary knob
Outputs 2 x CAN
1 x USB
1 x RS232
2 x M12 for two analogue cameras (optional for item no.: 30322512)
Pin assignment of ports A and B
Ports A and B are both CAN-interfaces.
Port B is not currently connected.
Pin assignment of the 9-pin D-sub port of the ISO agricultural machinery interface (CAN).
Pin no.: Signal: Pin no.: Signal
1 CAN_L 6 - Vin* (GND)
8.4.2
