Technical specifications
ECU-MIDI 3.0 job computer
ECU-MIDI 3.0 job computer
1st Processor:
32-bit ARM Cortex™-M4 CPU 168 MHz, 2048 KB flash; 256 KB RAM
2nd Processor:
32-bit ARM Cortex™-M4 CPU 168 MHz, 2048 KB flash; 256 KB RAM
External memory:
SPI-Flash 16 MB; SDRAM 16 MB; FRAM 16kByte
Connections:
▪ 42-pin connector for connecting actuators/sensors
▪ 2x 16-pin connector for power supply and CAN (ISOBUS & Salve
BUS)
The connectors can be locked and equipped with single conductor
insulations.
Interfaces:
Up to 3 CAN and 1 LIN, Ethernet via additional card (optional)
Power supply:
12 V electrical system (9-16 V), max. load 30 A (50 A fuse in the cabel
harness)
Power input (IN):
500 mA (at 14.4 V without power output, without supply to external
sensors)
Standby current (OFF):
70 μA (typ.)
Temperature range:
-40 … +70 ºC
Housing:
Anodized aluminium continuous cast casing, plastic lid with EPDM
seal and pressure compensation element, stainless steel screws
Protection rating:
IP6K6K
Environmental tests:
Vibration and shock testing in accordance with DIN EN 60068-2
Temperature testing in accordance with IEC68-2-14-Nb, IEC68-2-30
and IEC68-2-14Na
Protection testing in accordance with DIN EN 60529
Dimensions:
Approx. 262 mm x 148 mm x 62 mm (L x W x H, without connector)
Weight:
ca. 1 kg
