Muller Elektronik MIDI 3.0 User Manual

9
Technical specifications
ECU-MAXI 3.0 job computer
88
V1.20180921
30303187-02-EN
ECU-MAXI 3.0 job computer
ECU-MAXI 3.0 job computer
Main processor
32-bit ARM Cortex™-M3 CPU 120 MHz, 1024 KB flash; 128 KB RAM
3x I/O processors
32-bit ARM Cortex™-M3 CPU 120 MHz, 256 KB flash; 96 KB RAM
External memory:
SPI-Flash 2x 8 MB; SRAM 1 MB; EEPROM 16 Kbit; optional: FRAM
8/16 KByte
Connections:
▪ 3x 42-pin connector for connecting of actuators/sensors
▪ 2x 16-pin connector for power supply and CAN (ISOBUS & Salve
BUS)
The connectors can be locked and equipped with single conductor
insulations.
Interfaces:
External: up to 6 CAN interfaces and 3 LIN interfaces , Ethernet via
additional card (optional)
Power supply:
12 V electrical system (50 A fuse)
Power input (IN):
400 mA (at 14.4 V without power output, without supply to external
sensors)
Standby current (OFF):
70 μA
Temperature range:
-40 to +85°C (in accordance with IEC68-2-14-Nb, IEC68-2-30 and
IEC68-2-14Na)
Housing:
Anodized aluminium continuous cast casing, plastic lid with seal and
stainless steel screws
Protection rating:
IP66K
Environmental tests:
Vibration and shock testing in accordance with DIN EN 60068-2
Dimensions:
290 mm x 240 mm x 90 mm (L x W x H, without connector)
Weight:
3.0 kg
Available languages
You can set the following languages in the software for the operation of the implement:
Bulgarian, Croatian, Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Greek,
Hungarian, Italian, Latvian, Lithuanian, Norwegian, Portuguese, Polish, Romanian, Russian, Serbian,
Slovak, Slovenian, Spanish, Swedish, Turkish
9.2
9.3
