User Manual
4. Move cursor1 (CH1 zero position rotary control) and cursor2 (CH2 zero position
rotary control) to choose the range of wave to be cut.
5. Press the H2 button, and the input keyboard will pop up. The default name is the
current system date. Turn M rotary control to choose the keys, and press M rotary
control to input the chosen keys. Choose and press Enter key of the keyboard to end
the input and store the file with the current name to U-disk.
Figure 5-48: Cut Wave
To recall waveform：
(1) Enter the operation menu: Press →Editable Wform →SelectWform. Enter
the following interface:
Figure 5-49: Choose storage device
(2) Select USBDEVICE, enter Next Level. Turn the rotary control or press /
direction key to select the saved example.ota waveform file.
