9. Technical Specifications
Unless otherwise specified, the technical specifications applied are for MP720012
only, and Probes attenuation set as 10X. Only if the oscilloscope fulfills the following
two conditions at first, these specification standards can be reached.
 This instrument should run for at least 30 minutes continuously under the
specified operating temperature.
 If change of the operating temperature is up to or exceeds 5℃, do a
"Self-calibration" procedure (see "How to Implement Self-calibration" on P15).
All specification standards can be fulfilled, except one(s) marked with the word
"Typical".
Performance Characteristics
Instruction
Bandwidth
MP720012
100 MHz
Channel
2 + 1 (External)
Acquisition
Mode
Normal, Peak detect, Averaging
Sample Rate
MP720012
Dual CH
500MS/s
Single CH
1 GS /s
Input
Input coupling
DC, AC , Ground
Input impedance
1 MΩ ± 2%, in parallel with 15 pF ± 5 pF
Probe attenuation
factor
1X, 10X, 100X, 1000X
Max. input voltage
400 V (DC + AC Peak)
Channel –channel
isolation
50 Hz: 100 : 1
10 MHz: 40 : 1
Time delay between
channel(typical)
150 ps
Bandwidth limit
20 MHz, full bandwidth
(Only MP720012 has this function)
Dual CH
0.5S/s - 500MS/s
Single CH
0.5 S/s – 1 GS /s
Interpolation
(sin x)/x
Dual CH
≤Max
sampling rate
1 M (can be
upgraded to 10 M)
Single CH
2 ns/div – 100 s/div, step by 1 - 2 - 5
Sampling rate / relay
time accuracy
± 25 ppm
