Figure 5-76 Wave of Freq cursor measurement
How to Use Autoscale
This is a very useful function for first time users to carry out a simple and quick test on the
input signal. The function is applied to follow-up signals automatically even if the signals
change at any time. Autoscale enables the instrument to set up trigger mode, voltage
division and time scale automatically according to the type, amplitude and frequency of
the signals.
Figure 5-77 Autoscale menu
The menu is as follows:
Turn on Autoscale.
Turn off Autoscale.
To Next Page
