multicomp pro MP720012 User Manual

User Manual
99
General Technical Specifications
Display
Display Type
8" Coloured LCD (Liquid Crystal Display)
Display Resolution
800 (Horizontal) × 600 (Vertical) Pixels
Display Colours
65536 colours, TFT screen
Output of the Probe Compensator
Output Voltage (Typical )
About 5 V, with the Peak-to-Peak voltage ≥1 MΩ.
Frequency (Typical )
Square wave of 1 KHz
Power
Mains Voltage
100 - 240 VAC RMS, 50/60 Hz, CAT II
Power Consumption
< 15 W
Fuse
2 A, T grade, 250 V
Environment
Temperature
Working temperature: 0 ℃ - 40 ℃
Storage temperature: -20 ℃ - 60 ℃
Relative Humidity
≤ 90%
Height
Operating: 3,000 m
Non-operating: 15,000 m
Cooling Method
Natural convection
Mechanical Specifications
Dimension
348 mm × 170 mm × 78 mm (L*H*W)
Weight
About 1.5 kg
Interval Period of Adjustment:
One year is recommended for the calibration interval period.
