multicomp pro MP720012 User Manual

User Manual
98
Trigger:
Performance Characteristics
Instruction
Trigger level range
Internal
± 6 div from the screen center
EXT
± 600 mV
EXT/5
±3 V
Trigger level
Accuracy (typical)
Internal
±0.3 div
± (40 mV + 6% of Set Value)
EXT/5
± (200 mV + 6% of Set Value)
Trigger
displacement
According to Record length and time base
Trigger Holdoff
range
100 ns – 10 s
50% level setting
(typical)
Input signal frequency ≥50 Hz
Edge trigger
slope
Rising, Falling
Sensitivity
0.3 div
Pulse trigger
Trigger condition
Positive pulse：＞, ＜, ＝
negative pulse：＞, ＜, ＝
Pulse Width range
30 ns – 10 s
Video Trigger
Modulation
Support standard NTSC, PAL and SECAM
broadcast systems
Line number range
1-525 (NTSC) and 1-625 (PAL/SECAM)
Slope Trigger
Trigger condition
Positive pulse：＞, ＜, ＝
negative pulse：＞, ＜, ＝
Time setting
24 ns – 10 s
Alternate Trigger
Trigger on CH1
Edge, Pulse, Video, Slope
Trigger on CH2
Edge, Pulse, Video, Slope

multicomp pro MP720012 Specifications

General

Brand	multicomp pro
Model	MP720012
Category	Test Equipment
Language	English
