Performance Characteristics
Instruction
Interval(T)
accuracy
(DC - 100 MHz)
Single
± (1 interval time+25 ppm×reading+0.6 ns);
Average>16
± (1 interval time+25 ppm×reading+0.4 ns)
Vertical system
A/D converter
8 bits resolution (2 Channels simultaneously)
2 mV/div 10 V/div
± 1 V (2mV/div 100mV/div)
± 10 V (200 mV/div 1 V/div)
± 100 V (2 V/div 10 V/div)
100 MHz
Single bandwidth
Full bandwidth
Low Frequency
10 Hz (at input, AC coupling, -3 dB)
3.5 ns (at input, Typical)
DC gain accuracy
±3%
DC accuracy
(average)
Average16: ±(3% rdg + 0.05 div) for V
Waveform inverted ON/OFF
Measurement
Cursor
V and T between cursors
Automatic
Period, Freq, Mean, PK-PK, RMS, Max, Min,
Vtop, Vbase, Vamp, OverShoot, PreShoot, Rise
Time, Fall Time, +D width, -D width, +Duty,
-Duty, Delay A→B , Delay A→B , Cycle
RMS, Cursor RMS, Duty cycle, and Phase.
Waveform Math
, , *, / ,FFT
Waveform storage
15 waveforms
Lissajous
figure
Bandwidth
Full bandwidth
Phase
difference
±3 degrees
Communication
port
USB2.0, USB for file storage; LAN port;
VGA port or RS-232 (Optional);
