RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23) — PAGE 95
MAINTENANCE
105RAMMAX1575
1
555031
2
MAINTENANCE MANUAL
• Rell engine oil through one of two lling ports.
- Oil lling port on the left engine side (1)
- Oil lling port on the engine (2).
• Keep the level within the range of gauge marks pressed in
the dipstick. The lower mark shows the lowest possible oil
level, the upper mark the highest possible oil level.
Note
The total amount of oil in the engine is 3.4 l (0.9 US gal).
Beware of scalding when draining hot oil. Let oil cool
down to less than 50°C (122°F).
Follow the re safety measures!
Use recommended lters - see Spare parts catalogue.
Use recommended oil - see chapter 3.2.1.
Collect drained oil; donot let it soak into the ground.
Used oil and lters are environmentally dangerous waste
- have them liquidated.
