Munters Trio Poultry Controller - Wiring Diagrams

© Munters AB, 2020 15
Table 3: Sensors
Device type
Analog Sensors
Digital Sensors
Temperature Sensors 12 N/A
Humidity Sensors 2 N/A
Outside Humidity Sensor 1 N/A
CO2 Sensors 1 N/A
Ammonia Sensors 1 N/A
Pressure Sensors 2 N/A
Potentiometers 4 N/A
Bird Weighing 4 N/A
Silo Weighing 2 N/A
Lux Meter (light intensity) 1 N/A
Water Meters N/A 4
Gas Meters N/A 3
Aux. Input N/A 4
Auger Sensor N/A 2
Feeder Line Sensor N/A 4
NOTE Refer to Appendix A: External Devices (Previous Versions), page 93 to view details on the
input/output capacity of previous versions.
3.4 Wiring Diagrams
• High Voltage Relays
• Alarms and Power
• Internet Connection
• Analog Output Devices
• Digital Devices
• Analog Input Devices
• Trio RPS
• Bird Scale Card
• Silo Wiring
• RSU Wiring
