Munters Trio Poultry Controller - Internet Connection

134 pages

Save Page as PDF

To Next Page

To Previous Page

3.4.3

NTERNET

ONNECTION

Figure 8: Ethernet port

CAUTION

Connect the internet cable to port 2. Do not connect the cable to port 1.

1 Internal port (do not use this port)

2 Ethernet port

3 RJ-45 cable
