Manual MVK-MP
V 3.5 33
4.3.4.2. Data Format MVK AO4(I) Art.-No. 55292
Representation of analog values of input data 11 Bit.
Measuring range
0..20 mA
Measuring value
Range
binary
hexadecimal
decimal
20 mA
10 mA
4 mA
0 mA
0xxx x111 1111 1111
0xxx x011 1111 1111
0xxx x001 1001 1001
0xxx x000 0000 0000
07FF
03FF
0199
0000
2047
1023
409
0
Nominal Range
Tab. 6: Analog values MVK AO4(I) Art.-No. 55292 in the range of 0 ... 20 mA
Representation of analog values of output data 11 Bit.
Measuring range
4..20 mA
Measuring value
Range
binary
hexadecimal
decimal
20 mA
10 mA
4 mA
0xxx x111 1111 1111
0xxx x010 1111 1111
0xxx x000 0000 0000
07FF
02FF
0000
2047
767
0
Nominal Range
Tab. 7: Analog values MVK AO4(I) Art.-No. 55292 in the range of 4...20 mA
