Troubleshooting
30 AP-74700 – Rev. 1.0 – 10/03/2008
2.7 HEAD AND FLATCABLE RELATED ERRORS
E102 - Fuse 1 Error
E103 - Fuse 2 Error
E104 - Fuse 3 Error
E105 - Fuse 4 Error
E106 - Fuse 5 Error
E107 - Fuse 6 Error
E108 - Fuse 7 Error
E109 - Fuse 8 Error
E077 - Head OverHeat (Somewhere between head 1 and 8)
Æ Applicable on old mainboards (< Rev. W) only
E110 - Head Overheat 1
E111 - Head Overheat 2
E112 -Head Overheat 3
E113 - Head Overheat 4
E114 -Head Overheat 5
E115 - Head Overheat 6
E116 - Head Overheat 7
E117 - Head Overheat 8
The fuses protect the electronic driver components on the mainboard. Every ink-channel has a separate
fuse, so every printhead have 2 fuses, located on the main board below the Head Driver Board.
Old revision mainboards need some soldering, to remove the old fuse and to put a new one.
New revision boards (RoHS) do not need soldering. The fuse can easily be replaced as it is socketed.
Important
• ONLY USE THE FUSE DEFINED IN THE SPAREPARTS FROM MUTOH. DO NOT USE ANY OTHER FUSE AS WE
CANNOT GUARANTEE THE CORRECT TYPE USED
.
• P
LEASE REFER TO TIB 188 FOR MORE INFORMATION
