MUTOH ValueCut VC-600 - Replacing Pinch Roller Sets

MAINTENANCE MANUAL
VCE-MM-02
21
To Remove the Top Cover:
Replacing the Pinch Roller Sets
The following steps are those involved in replacing pinch roller sets.
To Unlatch the Pinch Roller Lever:
1. Unscrew the two screws at each end of the
Top Cover.
2. Unplug the Control Panel Cable before
removing the top cover completely.
1. Pull down the Square Bar Lever to unlatch
the Pinch Rollers
