MAINTENANCE MANUAL
VCE-MM-02
45
Diagnostic Test for SRAM and DRAM
This test provides the ability to diagnose the SRAM and DRAM. If these two components are bad,
replace them. Otherwise the cutting plotter will not work properly.
Diagnostic Test for Lever Sensor
This feature diagnoses the lever sensor. If the sensor is faulty, the cutting plotter cannot sense that
the pinch rollers have been lowered or not. If the lever sensor is down, you will see a lift the lever
message on the LCM. If the lever is up, you will see a lower the lever message on the LCM. You can
use the ON/OFF LINE KEY to abort your test when you have finished the lever sensor test.
[ENTER] Key [ON/OFF LINE] Key
Check Lever Sensor ?
Select:{} Ok:ENTER
Lever is Up now
ON/OFF
Lever is Down now
ON/OFF
To Next Page
