MAINTENANCE MANUAL
VCE-MM-02
46
Diagnostic Test for Media Sensors
This test is to diagnose the media sensors. If they are faulty, the cutting plotter cannot detect the
media length correctly. You can see the current front and rear sensor condition, you can turn it on or
off to see if sensors are out of order or not.
[ENTER] Key [ON/OFF LINE] Key
Paper sensor
Check Media Sensor ?
Select:{} Ok:ENTER
Now Front is OPEN
Rear is OPEN ON/OFF
Now Front is CLOSE
Rear is CLOSE ON/OFF
To Next Page
