MUTOH ValueCut VC-600 - Technical Specifications

MAINTENANCE MANUAL
VCE-MM-02
61
Specification
Model Number
VC-600
VC-1300
VC-1800
Operation Method
Paper Moving Type
Max. Cutting Width
610mm(24in)
1320mm(52in)
1830mm(72in)
Max. Cutting Length 50m(164ft)
Max. Media Loading Width
770mm(30.3in)
1594mm(62.7in)
1900mm(74.8in)
Min. Media Loading Width
50mm(1.97in)
300mm(11.8in)
Number of Pinch Rollers
3
4
6
Acceptable Material Thickness 0.8mm(0.03in)
Drive Motor
DC Servo Control
Cutting Force
5~600 g
Max. Cutting Speed
1530 mm/sec (60ips / Diagonal)
Acceleration 4.2 G (Gravity)
Blade Offset
0~1.0 mm (0.025mm/step)
Memory Buffer
4 MB
Interface
USB 2.0 (Full Speed) and Serial (RS-232C)
Type of Command HP-GL, HP-GL/2
Mechanical Resolution
0.006mm
Software Resolution
0.025 mm
Distance Accuracy
±0.254 mm or ±0.1% of move, whichever is greater
Repeatability ±0.1mm
Curve & Arc Smoothing
Yes
Configurable Origin
Yes
Test Cut capability
Yes
Tangential Yes
Repeat
Yes
Copy
Yes
Pouncing
Yes
Automatic-Aligning System Completely Automatic Contour Cutting System for print to cut solution
Control Panel
LCD (20 digits x 2lines), 14keys, 1 Power LED
Power Supply
AC 100-240V, 50~60 Hz (Auto switching)
Power Consumption
110 watts - 251.8 watts
Dimension (HxWxD) mm 412 * 950 * 486 1113 * 1774 * 651 1127 * 2170 * 756
Net Weight
18 kg
50 kg
64 kg
Stand
Optional
Standard
Media Basket
Optional
Standard
Operation
Environment
Temperature 15 ﾟ C – 30 ﾟ C, 60 ﾟ F – 86 ﾟ F
Humidity
25% - 75%
 The specification and data sheet may vary with different materials used. In order to obtain the
best output quality, please maintain the machine regularly and properly.
 MUTOH reserves the right to change the specifications at any time without notice.
 The above listed specification values are effective only when operated with media certified by
MUOTH.
