Diagnostic Test for Motor Encoder and Tool Holder Encoder
This feature provides the ability to diagnose the X and Y motor encoder and tool holder encoder. If
the encoder is defective, the cutting plotter cannot work properly. To check if the encoder is bad or
good, you can apply a slight force to the tested part (such as a drum, the tool carriage or the tool
holder) then examine the readings. If the encoder reading changes dramatically, the encoder is bad.
Refer to the maintenance chapter to replace the motor or tool carriage.
X Motor Encoder Test
Y Motor Encoder Test
[ENTER] Key
[ON/OFF LINE] Key
Seconds later
[ENTER] Key
[ON/OFF LINE] Key
Seconds later
X Motor Encoder ?
Select:{} Ok:ENTER
Move Drum By Hand
Wait for 3 seconds
X Encoder Reading
1234 ON/OFF
Y Motor Encoder ?
Select:{} Ok:ENTER
Move Carriage By Han
d Wait for 3 seconds
Y Encoder Reading
1234 ON/OFF
