MAINTENANCE MANUAL
VCE-MM-02
47
Diagnostic Test for Width Sensor
If the sensor is faulty, the cutter cannot sense the media width correctly. Refer to the maintenance
chapter to replace it. You must first move the tool carriage to the rightmost position; the lever must
be down to do this. Once this is done please move the tool carriage to left. Be careful when moving
the tool carriage close to the pinch roller, since the message changes quickly when sensor is between
on and off.
[ENTER] Key [ON/OFF LINE] Key
Width sensor
Check Width Sensor ?
Select:{} Ok:ENTER
Now Sensor is off
Move Carriage Slowly
Now Sensor is on
Move Carriage Slowly
To Next Page
