VJ-2638/1638X/1938WX/1638WX OPERATION MANUAL Before using
3.5 Test print 133
5. Press the [Enter] key on Operation panel.
• For VJ-2638/1638X, “Warming Up Skip ->E” is displayed on Operation panel.
(This is not displayed for VJ-1938WX/1638WX since it does not perform warming up.
• While “Warming Up” is displayed, do not touch Platen and Media guide.
They become very hot and you could burn yourself.
• You can start printing during warming up.
4.4.7 Starting printing during warming up (VJ-2638/1638X)
• Starts micro adjustment printing.
(VJ-2638/1638X starts printing after warming up is complete.)
• When "AdjustALL" is selected, six micro adjustment patterns A to F will be printed.
• When you have selected one of "Adjustment Pattern A" to "Adjustment Pattern F", the micro
adjustment pattern for the selected pattern is printed.
1234567
Pattern name
Print information
Uni dir
normal speed
large dot family
A
To Next Page
