MUTOH VJ-628 - 2). Confirm Print

MUTOH Status Monitor
Installation Wizard Operation Manual
3 Installation Wizard
3-136
MSMIE-A-01
2). Confirm Print
Prints the confirm print patterns to check the adjustment result.
No
Name
Contents
1
Next
Prints the confirm print patterns.
2
Skip
Go to the “Micro Adjustment” menu.
3
Back
Go back to the previous menu.
4
Pattern Print
Enter the feeding length by clicking the arrow key.
Adjustment range: 100mm - 500mm (in increment of 50mm)
*250mm is default value.
3
2
1
