N-Tron 7506GX2 User Manual

(Revised 2011-07-21) Page 137 of 158
CLI Commands, Continued…
Show or Set Mirror Configuration
Command Name
Mirror
Description
Show or set Mirror configuration. If no parameters are specified, this command will
show the Mirror configuration (same as -show parameter).
Syntax
mirror [-show] [-status state] [-dp portno] [-tx portlist] [-rx portlist]
Parameters
-show
Show configuration.
-status state
Set the Mirror status to e(nabled) or d(isabled).
-dp portno
Set the destination port number for mirrored frames.
-tx portlist
Set the source ports to mirror frames that are transmitted.
-rx portlist
Set the source ports to mirror frames that are received.
Examples
N-TRON/Admin> mirror –show
Mirror Status : Disabled
Destination Port : TX
Tx Source Ports : (None)
Rx Source Ports : (None)
N-TRON/Admin> mirror –status enabled –dp 6 –tx 1,3-5 –rx 1,3,5
Mirror Status : Enabled
Destination Port : GB2
Tx Source Ports : T1, T3-GB1
Rx Source Ports : T1, T3, GB1
Changes have been made that have not been saved.
…
NOTES
The portlist consists of port numbers and ranges, separated by commas. It may not
contain space characters. Use ―all‖ to set all ports as source ports, and use ―none‖ to clear
all ports from source ports.
