(Revised 2011-07-21) Page 151 of 158
Example 2 – Basic understanding of tagged VLANs (Admit – Tagged Only)
Receiving
Port #
Tagged VID
in packet
Destination
Address
Transmitting
Port #s
Notes
TX1
Untagged
MAC on port TX2
--
Packet Discarded
TX1
VID 2
MAC on port TX2
TX2
Unicast Traffic
TX1
VID 4
MAC on port TX2
--
Packet Discarded
TX1
VID 2
MAC on port TX5
TX2
Floods VLAN 2
TX3
Untagged
MAC on port TX1
--
Packet Discarded
TX3
VID 1
MAC on port TX6
TX6
Unicast Traffic
TX3
VID 1
Unknown MAC
TX5-TX8
Floods VLAN 1
TX3
VID 4
MAC on port TX8
--
Packet Discarded
