N-Tron 7506GX2 User Manual

(Revised 2011-07-21) Page 5 of 158
PRODUCT FEATURES
• Full IEEE 802.3 Compliance
• Four 10/100/1000BaseT(X) RJ-45 Ports
• Two SFP (Mini-GBIC) Gigabit Transceivers
(Optional)
o 1000BaseSX/LX Fiber with LC style connectors
or
o 1000BaseT Copper with RJ-45 connectors
• Extended Environmental Specifications
-40° to 80°C Surrounding Air Temperature
• ESD and Surge Protection Diodes on all Ports
• Auto Sensing 10/100/1000BaseT(X), Duplex, and
MDIX
• Store-and-forward Technology
• Rugged DIN-Rail Enclosure
• Onboard Temperature Sensor
• Redundant Power Inputs (10-49VDC)
• Configurable Bi-Color Fault Status LED
PRODUCT CONFIGURATIONS
• 7506GX2
– Four 10/100/1000 Base-T RJ45 Copper Ports,
and two optional SFP transceivers
Supported SFP (Mini-GBIC) Fiber Transceivers:
NTSFP-SX (LC Style Connector, up to 550m)
NTSFP-LX-10 (LC Style Connector, up to 10km)
NTSFP-LX-40 (LC Style Connector, up to 40km)
NTSFP-LX-80 (LC Style Connector, up to 80km)
MANAGEMENT FEATURES
• SNMP v1, v2, v3 and Web Browser Management
• Configuration backup via Optional Configuration Device (NTCD)
• Jumbo Frame Support
• EtherNet/IP™ CIP Messaging
• Detailed Ring Map and Fault Location Charting
• N-Ring™ Technology with ~30ms Healing
• Web Browser Management with detailed ring map and
fault location charting.
• N-View™ OPC Monitoring
• N-Link™ Redundant N-Ring Coupling
• IGMP Auto Configuration and Plug and Play Support
• 802.1Q tag VLAN and Port VLAN
• 802.1p QoS, Port QoS, and DSCP
• LLDP (Link Layer Discovery Protocol)
• Trunk with other N-Tron trunking capable switches over two ports
• Port Mirroring
• 802.1d, 802.1w, 802.1D RSTP (Rapid Spanning Tree Protocol)
• DHCP Client, Server, Option 82 relay, Option 61
• Local Port IP Addressing
• Port Security—MAC Address Based
