GENERAL
03-M-E3B, 03-M-DI-E3B, 03-M-E3BG, WSM
G-30
[13] CHECK POINTS FOR EVERY 3000 HOURS
Check of Turbocharger
Turbine Side
1. Examine the exhaust port (2) and the inlet port (3) side of the
turbine housing (1) for exhaust gas leakage.
2. If you find a gas leakage, tighten the bolts and nuts again or
replace the gasket with a new one.
Compressor Side
1. Examine the inlet hose (4) of the compressor cover (5) for air
leakage.
2. Examine the suction side of the intake hose for loose
connections or cracks.
3. If you find an air leakage, change the clamp (6) and / or the inlet
hoses.
Radial Clearance
1. If the wheel touches the housing, replace the turbocharger
assembly with a new one.
M00000003GEG0045US1
(1) Turbine Housing
(2) Exhaust Port
(3) Inlet Port
(4) Inlet Hose
(5) Compressor Cover
(6) Clamp
