ENGINE
03-M-E3B, 03-M-DI-E3B, 03-M-E3BG, WSM
1-S19
ELECTRICAL SYSTEM
M00000003ENS0007US1
Injection Nozzle Valve Seat
[D1803-M-DI, V2403-M-DI, V2403-M-DI-T]
Valve Seat
Tightness
No fuel leak at
16.67 MPa
170.0 kgf/cm
2
2418 psi
–
Item Factory Specification Allowable Limit
Starter
• Commutator
[D1503-M, D1703-M, V2003-M,
V2203-M, D1803-M-DI, D1703-M-BG,
V2003-M-BG, V2003-M-T-BG,
V2203-M-BG]
[D1803-M, V2403-M, V2403-M-DI,
V2403-M-T, V2403-M-DI-T,
V2403-M-BG]
•Mica
[D1503-M, D1703-M, D1803-M,
V2003-M, V2203-M, V2403-M,
V2403-M-T, D1803-M-DI, V2403-M-DI,
V2403-M-DI-T, D1703-M-BG,
V2003-M-BG, V2003-M-T-BG,
V2203-M-BG]
•Mica
[V2403-M-BG]
•Brush
[D1503-M, D1703-M, V2003-M,
V2203-M, D1803-M-DI, D1703-M-BG,
V2003-M-BG, V2003-M-T-BG,
V2203-M-BG]
•Brush
[D1803-M, V2403-M, V2403-M-DI,
V2403-M-T, V2403-M-DI-T]
•Brush
[V2403-M-BG]
• Brush Holder and Holder Support
O.D.
O.D.
Undercut
Undercut
Length
Length
Length
Resistance
30.0 mm
1.18 in.
35.0 mm
1.38 in.
0.45 to 0.75 mm
0.018 to 0.029 in.
0.55 to 0.85 mm
0.022 to 0.033 in.
15.0 mm
0.591 in.
15.0 mm
0.591 in.
15.0 mm
0.591 in.
Infinity
29.0 mm
1.14 in.
34.0 mm
1.34 in.
0.20 mm
0.0079 in.
0.20 mm
0.0079 in.
11.0 mm
0.433 in.
9.0 mm
0.35 in.
12.0 mm
0.472 in.
–
Alternator
• Stator
• Rotor
• Slip Ring
•Brush
No-load voltage
Resistance
Resistance
O.D.
Length
More than 13.5 V
Less than 1.0 Ω
2.9 Ω
14.4 mm
0.567 in.
10.5 mm
0.413 in.
–
–
–
14.0 mm
0.551 in.
8.4 mm
0.33 in.
Glow Plug Resistance Approx. 0.9 Ω –
Item Factory Specification Allowable Limit
KiSC issued 06, 2009 A
