ENGINE
03-M-E3B, 03-M-DI-E3B, 03-M-E3BG, WSM
1-S29
(Continued)
• The sealant is applied to the 2 sides of the soft metal gasket
shim. The liquid gasket is not necessary to assemble.
• The shims are available in thickness of 0.175 mm
(0.00689 in.) (6), 0.20 mm (0.0079 in.) (3), 0.25 mm
(0.0098 in.) (4) and 0.30 mm (0.012 in.) (5). Make a
combination of these shims for adjustment.
• The 0.175 mm (0.00689 in.) thick shim has only a thin layer
on the lower face. Thus, do not use the 0.175 mm
(0.00689 in.) thick shim as the top shim of the combination
(injection pump side). If not, it can cause oil leakage.
• Addition or reduction of shim (0.05 mm, 0.002 in.) delays or
advances the injection timing by approx. 0.009 rad (0.5 °).
• When you disassemble or replace, make sure that you use
the same number of new gasket shims with the same
thickness.
M00000003ENS0026US1
