VS1 Operations and Maintenance Manual Operating the transmitter
Page 2-154 Issue 3.1 2013-10-01
Use the up and down buttons to select the desired analog output (1 through 4) from the list. Each
screen shows the analog output parameter (e.g., Forward Power, Reflected Power, Avg PA Volts or
Total PA Current), as well as the meter reading (actual and full-scale) and the output pin voltage
(actual and full-scale). Press cancel (X) to return to the previous menu.
Note:
The analog output’s Output voltage reading reflects the value that can be measured at the
associated remote analog output pin for the given Meter value. See the Pre-installation Manual for
actual remote analog output pin assignments.
