VS1 Operations and Maintenance Manual Non-standard maintenance
Issue 3.1 2013-10-01 Page 4-3
Transfer software upgrade file to transmitter
1. If using a laptop, connect the laptop network interface card to the transmitter LAN (A1J8A)
connector on the rear panel using a CAT5 Ethernet cable. Open Internet Explorer and
search for 10.10.10.2. The transmitter login screen should appear.
2. If using a network computer, open Internet Explorer and search for the IP address recorded
in Step 2 of “Transmitter IP configuration” on page 4-2. The transmitter login screen should
appear.
3. At the transmitter login screen enter:
– User: “Nautel” or “****”, where **** is the user assigned user name
– Password: leave blank (default) or “****”, where **** is the user assigned password
4. Navigate through the AUI to Menu/System Settings/Upgrade Software and press
Manage Files/Browse. Locate the software update *.tgz file and press Upload to load the
file into the transmitter Select Upgrade File list.
