Navistar WorkStar Series User Manual

Controls/Features
Alarm Conditions Audible Alarm Pattern Additional Comments
Engine Oil Temperature Gauge out of range reading 5 BEEPS Instrument Panel Gauge Cluster warning indicator
illuminates.
Engine Coolant Temperature Gauge out of range reading 5 BEEPS Instrument Panel Gauge Cluster warning indicator
illuminates.
Transmission Oil Temperature Gauge out of range reading 5 BEEPS Instrument Panel Gauge Cluster warning indicator
illuminates.
Rear-Rear Axle Oil Temperature Gauge out of range reading 5 BEEPS Instrument Panel Gauge Cluster warning indicator
illuminates.
Forward-Rear Axle Oil Temperature Gauge out of range
reading
5 BEEPS Instrument Panel Gauge Cluster warning indicator
illuminates.
Auxiliary Air Pressure Gauge out of range reading 5 BEEPS Instrument Panel Gauge Cluster warning indicator
illuminates.
Gauge Sensor Faults 3 BEEPS Gauge pointer goes to 6 o’clock position and
Instrument Panel Gauge Cluster warning indicator
illuminates.
Primary Air Pressure Gauge out of range and air pressure
sensor fault
REPEATING SINGLE
BEEP
Instrument Panel Gauge Cluster warning indicator
illuminates.
Secondary Air Pressure Gauge out of range and air pressure
sensor fault
REPEATING SINGLE
BEEP
Instrument Panel Gauge Cluster warning indicator
illuminates.
RedStopWarningindicator illuminates REPEATING SINGLE
BEEP
Instrument panel warning indicator illuminates.
Turn Signal Alarm (Optional) CONTINUOUS TONE Alarm sounds if either turn signal is on for more than
one mile.
Will not activate when hazard flashers are on.
Low Coolant Alarm REPEATING SINGLE
BEEP
Gauge warning indicator illuminates.
46 3879634R1
