Controls/Features
Center Dash Panel/Wing Panel
The Center Control Switch Panel consists of the switches
that start the vehicle, control the vehicle’s normal operations,
vehicle lights, and special mechanical functions. The panel also
includes control of the interior comfort levels (HVAC controls),
optional parking brake controls and auxiliary electrical power
source (see Vehicle Operation for operational details). Refer
to the Radio Operator’s Manual provided with the vehicle for
instructions on operating the radio installed in this Vehicle.
1. Radio
2. Fan Speed Control
3. Temperature Control
4. Mode Control
5. Storage Compartment/Optional Switch Pack Location
6. Parking Brake
7. Optional Component Panel
8. Trailer Air Supply
9. Optional Switch Pack Location
10. Ignition Switch
11. Switch Pack
74 3879634R1
